UC2856DWTR

Part No :: UC2856DWTR

Manufacturer: VIGOR

VIGOR # :: 3855988

Description: UC2856 IMPROVED CURRENT MODE PWM

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: UC2856DWTR PDF

Country of origin: -

Date code: -

UC2856DWTR Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up, Step-Up/Step-Down
Output Configuration:	Positive
Topology:	Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
Number of Outputs:	2
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	7V ~ 40V
Frequency - Switching:	200kHz
Duty Cycle (Max):	47%
Synchronous Rectifier:	Yes
Clock Sync:	Yes
Serial Interfaces:	-
Control Features:	Enable, Frequency Control, Soft Start
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	16-SOIC
