UC3842AN1

Part No :: UC3842AN1

Manufacturer: VIGOR

VIGOR # :: 3856458

Description: ANA SMPS PWM CONTROLLER

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: UC3842AN1 PDF

Country of origin: -

Date code: -

UC3842AN1 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up, Step-Down, Step-Up/Step-Down
Output Configuration:	Positive, Isolation Capable
Topology:	Boost, Buck, Flyback, Forward
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	10V ~ 30V
Frequency - Switching:	Up to 500kHz
Duty Cycle (Max):	96%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Frequency Control
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Through Hole
Package / Case:	8-DIP (0.300", 7.62mm)
Supplier Device Package:	8-PDIP
