MIC3809YM

Part No :: MIC3809YM

Manufacturer: Roving Networks / Microchip Technology

VIGOR # :: 3856624

Description: IC REG CTRLR MULT TOPOLOGY 8SOIC

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: MIC3809YM PDF

Country of origin: -

Date code: -

MIC3809YM Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Output Type:	Transistor Driver
Function:	Step-Up/Step-Down
Output Configuration:	Positive, Isolation Capable
Topology:	Full-Bridge, Half-Bridge, Push-Pull
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	2V ~ 14V
Frequency - Switching:	200kHz
Duty Cycle (Max):	49%
Synchronous Rectifier:	No
Clock Sync:	No
Serial Interfaces:	-
Control Features:	Frequency Control
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
