LM5020SDX-1

Part No :: LM5020SDX-1

Manufacturer: Texas Instruments

VIGOR # :: 4895505

Description: IC REG CTRLR FLYBACK 10WSON

Catalog: PMIC - Voltage Regulators - DC DC Switching Controllers

DataSheet: LM5020SDX-1 PDF

Country of origin: -

Date code: -

LM5020SDX-1 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Output Type:	Transistor Driver
Function:	Step-Up/Step-Down
Output Configuration:	Positive
Topology:	Flyback
Number of Outputs:	1
Output Phases:	1
Voltage - Supply (Vcc/Vdd):	8V ~ 15V
Frequency - Switching:	200kHz ~ 630kHz
Duty Cycle (Max):	80%
Synchronous Rectifier:	No
Clock Sync:	Yes
Serial Interfaces:	-
Control Features:	Frequency Control, Soft Start
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	10-WDFN Exposed Pad
Supplier Device Package:	10-WSON (4x4)
