AP1509-12SG-13

Part No :: AP1509-12SG-13

Manufacturer: Zetex Semiconductors (Diodes Inc.)

VIGOR # :: 3888872

Description: IC REG BUCK 12V 2A 8SOP

Catalog: PMIC - Voltage Regulators - DC DC Switching Regulators

DataSheet: AP1509-12SG-13 PDF

Country of origin: -

Date code: -

AP1509-12SG-13 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)Cut Tape (CT)
Part Status:	Obsolete
Function:	Step-Down
Output Configuration:	Positive
Topology:	Buck
Output Type:	Fixed
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	22V
Voltage - Output (Min/Fixed):	12V
Voltage - Output (Max):	-
Current - Output:	2A
Frequency - Switching:	150kHz
Synchronous Rectifier:	No
Operating Temperature:	-20°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOP
