LM2696MXAX/NOPB

Part No :: LM2696MXAX/NOPB

Manufacturer: Texas Instruments

VIGOR # :: 3893357

Description: IC REG BUCK ADJ 3A 16HTSSOP

Catalog: PMIC - Voltage Regulators - DC DC Switching Regulators

DataSheet: LM2696MXAX/NOPB PDF

Country of origin: -

Date code: -

LM2696MXAX/NOPB Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Function:	Step-Down
Output Configuration:	Positive
Topology:	Buck
Output Type:	Adjustable
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	24V
Voltage - Output (Min/Fixed):	1.254V
Voltage - Output (Max):	20V
Current - Output:	3A
Frequency - Switching:	100kHz ~ 500kHz
Synchronous Rectifier:	No
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	16-PowerTSSOP (0.173", 4.40mm Width)
Supplier Device Package:	16-HTSSOP
