MP2309DS-LF-Z

Part No :: MP2309DS-LF-Z

Manufacturer: MPS (Monolithic Power Systems)

VIGOR # :: 3897227

Description: IC REG BUCK ADJUSTABLE 1A 8SOIC

Catalog: PMIC - Voltage Regulators - DC DC Switching Regulators

DataSheet: MP2309DS-LF-Z PDF

Country of origin: -

Date code: -

MP2309DS-LF-Z Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Not For New Designs
Function:	Step-Down
Output Configuration:	Positive
Topology:	Buck
Output Type:	Adjustable
Number of Outputs:	1
Voltage - Input (Min):	4.75V
Voltage - Input (Max):	23V
Voltage - Output (Min/Fixed):	0.923V
Voltage - Output (Max):	20V
Current - Output:	1A
Frequency - Switching:	340kHz
Synchronous Rectifier:	Yes
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
LM2672M-ADJ Match 100%	VIGOR SWITCHING REG, VOLTAGE-MODE, 2.2	MP2309DS-LF-Z vs LM2672M-ADJ
MAX5035BASA+T Match 100%	Maxim Integrated IC REG BUCK 5V 1A 8SOIC	MP2309DS-LF-Z vs MAX5035BASA+T
TPS5410DRG4 Match 100%	Texas Instruments IC REG BUCK ADJUSTABLE 1A 8SOIC	MP2309DS-LF-Z vs TPS5410DRG4
MAX5035EASA+ Match 100%	Maxim Integrated IC REG BUCK ADJUSTABLE 1A 8SOIC	MP2309DS-LF-Z vs MAX5035EASA+
LM2672MX-ADJ/NOPB Match 100%	Texas Instruments IC REG BUCK ADJUSTABLE 1A 8SOIC	MP2309DS-LF-Z vs LM2672MX-ADJ/NOPB
LM2672M-12 Match 100%	VIGOR SWITCHING REG, VOLTAGE-MODE, 2.2	MP2309DS-LF-Z vs LM2672M-12
