MAX1680ESA+T

Part No :: MAX1680ESA+T

Manufacturer: Maxim Integrated

VIGOR # :: 3903741

Description: IC REG CHARGE PUMP INV 8SOIC

Catalog: PMIC - Voltage Regulators - DC DC Switching Regulators

DataSheet: MAX1680ESA+T PDF

Country of origin: -

Date code: -

MAX1680ESA+T Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Function:	Ratiometric
Output Configuration:	Positive or Negative
Topology:	Charge Pump
Output Type:	Fixed
Number of Outputs:	1
Voltage - Input (Min):	2V
Voltage - Input (Max):	5.5V
Voltage - Output (Min/Fixed):	-Vin, 2Vin
Voltage - Output (Max):	-
Current - Output:	125mA
Frequency - Switching:	125kHz, 250kHz
Synchronous Rectifier:	No
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
