MAX765ESA

Part No :: MAX765ESA

Manufacturer: VIGOR

VIGOR # :: 3904011

Description: MAX765 8-CHANNEL LATCHABLE MUX

Catalog: PMIC - Voltage Regulators - DC DC Switching Regulators

DataSheet: MAX765ESA PDF

Country of origin: -

Date code: -

MAX765ESA Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Function:	Step-Up/Step-Down
Output Configuration:	Negative
Topology:	Buck-Boost
Output Type:	Adjustable (Fixed)
Number of Outputs:	1
Voltage - Input (Min):	3V
Voltage - Input (Max):	16V
Voltage - Output (Min/Fixed):	-1V (-12V)
Voltage - Output (Max):	-16V
Current - Output:	120mA
Frequency - Switching:	300kHz
Synchronous Rectifier:	No
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
