CS8140YN14

Part No :: CS8140YN14

Manufacturer: VIGOR

Description: IC REG LINEAR 5V 500MA 14DIP

Catalog: PMIC - Voltage Regulators - Linear

DataSheet: CS8140YN14 PDF

Availability: 1425 pieces

Current price of CS8140YN14 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CS8140YN14 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Output Configuration:	Positive
Output Type:	Fixed
Number of Regulators:	1
Voltage - Input (Max):	26V
Voltage - Output (Min/Fixed):	5V
Voltage - Output (Max):	-
Voltage Dropout (Max):	1.5V @ 500mA
Current - Output:	500mA
Current - Quiescent (Iq):	-
Current - Supply (Max):	-
PSRR:	75dB (120Hz)
Control Features:	Enable, Reset
Protection Features:	Over Temperature, Short Circuit
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Through Hole
Package / Case:	14-DIP (0.300", 7.62mm)
Supplier Device Package:	14-PDIP

Please confirm the specifications of the products when ordering.
