| Type | Description |
|---|---|
| Series: | S-814 |
| Package: | Tape & Reel (TR) |
| Part Status: | Not For New Designs |
| Output Configuration: | Positive |
| Output Type: | Fixed |
| Number of Regulators: | 1 |
| Voltage - Input (Max): | 10V |
| Voltage - Output (Min/Fixed): | 4.7V |
| Voltage - Output (Max): | - |
| Voltage Dropout (Max): | 0.22V @ 60mA |
| Current - Output: | 135mA |
| Current - Quiescent (Iq): | 500 nA |
| Current - Supply (Max): | 40 µA |
| PSRR: | 45dB (100Hz) |
| Control Features: | Enable |
| Protection Features: | Short Circuit |
| Operating Temperature: | -40°C ~ 85°C (TA) |
| Mounting Type: | Surface Mount |
| Package / Case: | SOT-89-5/6 |
| Supplier Device Package: | SOT-89-5 |
| Part Number | Manufacturer & Description | Compare |
|---|---|---|
| S-814A46AUC-BDKT2G Match 100% |
ABLIC U.S.A. Inc.
IC REG LINEAR 4.6V 135MA SOT89-5
|
S-814A47AUC-BDLT2G vs S-814A46AUC-BDKT2G |
| S-814A49AUC-BDNT2G Match 100% |
ABLIC U.S.A. Inc.
IC REG LINEAR 4.9V 135MA SOT89-5
|
S-814A47AUC-BDLT2G vs S-814A49AUC-BDNT2G |
| S-814A48AUC-BDMT2G Match 100% |
ABLIC U.S.A. Inc.
IC REG LINEAR 4.8V 135MA SOT89-5
|
S-814A47AUC-BDLT2G vs S-814A48AUC-BDMT2G |
| S-818A49AUC-BHDT2G Match 56% |
ABLIC U.S.A. Inc.
IC REG LINEAR 4.9V 250MA SOT89-5
|
S-814A47AUC-BDLT2G vs S-818A49AUC-BHDT2G |
| S-814A45AUC-BDJT2G Match 100% |
ABLIC U.S.A. Inc.
IC REG LINEAR 4.5V 135MA SOT89-5
|
S-814A47AUC-BDLT2G vs S-814A45AUC-BDJT2G |
| S-818A45AUC-BGZT2G Match 56% |
ABLIC U.S.A. Inc.
IC REG LINEAR 4.5V 250MA SOT89-5
|
S-814A47AUC-BDLT2G vs S-818A45AUC-BGZT2G |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 1000 |
Current price of S-814A47AUC-BDLT2G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
