MC7805ABTG

Part No :: MC7805ABTG

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: IC REG LINEAR 5V 1A TO220AB

Catalog: PMIC - Voltage Regulators - Linear

DataSheet: MC7805ABTG PDF

Availability: 1912 pieces

Current price of MC7805ABTG is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

MC7805ABTG Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Output Configuration:	Positive
Output Type:	Fixed
Number of Regulators:	1
Voltage - Input (Max):	35V
Voltage - Output (Min/Fixed):	5V
Voltage - Output (Max):	-
Voltage Dropout (Max):	2V @ 1A (Typ)
Current - Output:	1A
Current - Quiescent (Iq):	6 mA
Current - Supply (Max):	-
PSRR:	83dB (120Hz)
Control Features:	-
Protection Features:	Over Temperature, Short Circuit
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Through Hole
Package / Case:	TO-220-3
Supplier Device Package:	TO-220AB
