MC7812BTG

MC7812BTG Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Output Configuration:	Positive
Output Type:	Fixed
Number of Regulators:	1
Voltage - Input (Max):	35V
Voltage - Output (Min/Fixed):	12V
Voltage - Output (Max):	-
Voltage Dropout (Max):	2V @ 1A (Typ)
Current - Output:	1A
Current - Quiescent (Iq):	8 mA
Current - Supply (Max):	-
PSRR:	60dB (1kHz)
Control Features:	-
Protection Features:	Over Temperature, Short Circuit
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Through Hole
Package / Case:	TO-220-3
Supplier Device Package:	TO-220AB

Alternative Products

Part Number	Manufacturer & Description	Compare
MC7808ABTG Match 100%	Sanyo Semiconductor/ON Semiconductor IC REG LINEAR 8V 1A TO220AB	MC7812BTG vs MC7808ABTG
MC7805ABTG Match 100%	Sanyo Semiconductor/ON Semiconductor IC REG LINEAR 5V 1A TO220AB	MC7812BTG vs MC7805ABTG
MC7815BTG Match 100%	Sanyo Semiconductor/ON Semiconductor IC REG LINEAR 15V 1A TO220AB	MC7812BTG vs MC7815BTG
MC7806BTG Match 100%	Sanyo Semiconductor/ON Semiconductor IC REG LINEAR 6V 1A TO220AB	MC7812BTG vs MC7806BTG
NCV7805BTG Match 100%	Sanyo Semiconductor/ON Semiconductor IC REG LINEAR 5V 1A TO220AB	MC7812BTG vs NCV7805BTG
MC7824BTG Match 100%	Sanyo Semiconductor/ON Semiconductor IC REG LINEAR 24V 1A TO220AB	MC7812BTG vs MC7824BTG
