MC7812BT

MC7812BT Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Output Configuration:	Positive
Output Type:	Fixed
Number of Regulators:	1
Voltage - Input (Max):	35V
Voltage - Output (Min/Fixed):	12V
Voltage - Output (Max):	-
Voltage Dropout (Max):	2V @ 1A (Typ)
Current - Output:	1A
Current - Quiescent (Iq):	8 mA
Current - Supply (Max):	-
PSRR:	60dB (1kHz)
Control Features:	-
Protection Features:	Over Temperature, Short Circuit
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Through Hole
Package / Case:	TO-220-3
Supplier Device Package:	TO-220AB

Alternative Products

Part Number	Manufacturer & Description	Compare
L7806ABV Match 71%	STMicroelectronics IC REG LINEAR 6V 1.5A TO220AB	MC7812BT vs L7806ABV
L7809ABV-DG Match 71%	STMicroelectronics IC REG LINEAR 9V 1.5A TO220AB	MC7812BT vs L7809ABV-DG
L7812ABV Match 71%	STMicroelectronics IC REG LINEAR 12V 1.5A TO220AB	MC7812BT vs L7812ABV
MC7815ABT Match 100%	Sanyo Semiconductor/ON Semiconductor IC REG LINEAR 15V 1A TO220AB	MC7812BT vs MC7815ABT
NCV7805BT Match 100%	Sanyo Semiconductor/ON Semiconductor IC REG LINEAR 5V 1A TO220AB	MC7812BT vs NCV7805BT
MC7812ABT Match 100%	Sanyo Semiconductor/ON Semiconductor IC REG LINEAR 12V 1A TO220AB	MC7812BT vs MC7812ABT
