ISO7041FDBQ

Part No :: ISO7041FDBQ

Manufacturer: Texas Instruments

Description: DGTL ISO 3000VRMS 4CH GP 16SSOP

Catalog: Digital Isolators

DataSheet: ISO7041FDBQ PDF

Availability: 1044 pieces

Current price of ISO7041FDBQ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ISO7041FDBQ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Technology:	Capacitive Coupling
Type:	General Purpose
Isolated Power:	No
Number of Channels:	4
Inputs - Side 1/Side 2:	3/1
Channel Type:	Unidirectional
Voltage - Isolation:	3000Vrms
Common Mode Transient Immunity (Min):	50kV/µs
Data Rate:	2Mbps
Propagation Delay tpLH / tpHL (Max):	165ns, 165ns
Pulse Width Distortion (Max):	10ns
Rise / Fall Time (Typ):	5ns, 5ns (Max)
Voltage - Supply:	2.25V ~ 3.6V
Operating Temperature:	-55°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	16-SSOP (0.154", 3.90mm Width)
Supplier Device Package:	16-SSOP
