ISO7831DW

Part No :: ISO7831DW

Manufacturer: Texas Instruments

Description: DGTL ISO 5700VRMS 3CH GP 16SOIC

Catalog: Digital Isolators

DataSheet: ISO7831DW PDF

Availability: 0 pieces

Current price of ISO7831DW is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ISO7831DW Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Technology:	Capacitive Coupling
Type:	General Purpose
Isolated Power:	No
Number of Channels:	3
Inputs - Side 1/Side 2:	2/1
Channel Type:	Unidirectional
Voltage - Isolation:	5700Vrms
Common Mode Transient Immunity (Min):	70kV/µs
Data Rate:	100Mbps
Propagation Delay tpLH / tpHL (Max):	16ns, 16ns
Pulse Width Distortion (Max):	4.1ns
Rise / Fall Time (Typ):	1.7ns, 1.9ns
Voltage - Supply:	2.25V ~ 5.5V
Operating Temperature:	-55°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	16-SOIC
