ISO7420DR

Part No :: ISO7420DR

Manufacturer: Texas Instruments

VIGOR # :: 4079641

Description: DGTL ISO 2500VRMS 2CH GP 8SOIC

Catalog: Digital Isolators

DataSheet: ISO7420DR PDF

Country of origin: -

Date code: -

ISO7420DR Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Technology:	Capacitive Coupling
Type:	General Purpose
Isolated Power:	No
Number of Channels:	2
Inputs - Side 1/Side 2:	2/0
Channel Type:	Unidirectional
Voltage - Isolation:	2500Vrms
Common Mode Transient Immunity (Min):	25kV/µs
Data Rate:	1Mbps
Propagation Delay tpLH / tpHL (Max):	14ns, 14ns
Pulse Width Distortion (Max):	3.7ns
Rise / Fall Time (Typ):	1ns, 1ns
Voltage - Supply:	3.15V ~ 3.45V, 4.75V ~ 5.25V
Operating Temperature:	-40°C ~ 105°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
