ACPL-H342-000E

Part No :: ACPL-H342-000E

Manufacturer: Broadcom

VIGOR # :: 4087715

Description: OPTOISO 3.75KV 1CH GATE DRVR 8SO

Catalog: Isolators - Gate Drivers

DataSheet: ACPL-H342-000E PDF

Country of origin: -

Date code: -

ACPL-H342-000E Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Technology:	Optical Coupling
Number of Channels:	1
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	25kV/µs
Propagation Delay tpLH / tpHL (Max):	350ns, 250ns
Pulse Width Distortion (Max):	-
Rise / Fall Time (Typ):	22ns, 18ns
Current - Output High, Low:	2A, 2A
Current - Peak Output:	2.5A
Voltage - Forward (Vf) (Typ):	1.55V
Current - DC Forward (If) (Max):	25 mA
Voltage - Output Supply:	15V ~ 30V
Operating Temperature:	-40°C ~ 105°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.268", 6.81mm Width)
Supplier Device Package:	8-SO
Approval Agency:	CSA, UR
