ACPL-335J-500E

Part No :: ACPL-335J-500E

Manufacturer: Broadcom

VIGOR # :: 4087816

Description: OPTOISO 5KV 1CH GATE DRIVER 16SO

Catalog: Isolators - Gate Drivers

DataSheet: ACPL-335J-500E PDF

Country of origin: -

Date code: -

ACPL-335J-500E Specifications

Type	Description
Series:	Automotive, AEC-Q100
Package:	Tape & Reel (TR)
Part Status:	Active
Technology:	Optical Coupling
Number of Channels:	1
Voltage - Isolation:	5000Vrms
Common Mode Transient Immunity (Min):	50kV/µs
Propagation Delay tpLH / tpHL (Max):	250ns, 250ns
Pulse Width Distortion (Max):	100ns
Rise / Fall Time (Typ):	60ns, 50ns
Current - Output High, Low:	-
Current - Peak Output:	2.5A
Voltage - Forward (Vf) (Typ):	1.55V
Current - DC Forward (If) (Max):	20 mA
Voltage - Output Supply:	12V ~ 20V
Operating Temperature:	-40°C ~ 105°C
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	16-SO
Approval Agency:	CSA, IEC/EN/DIN, UR
