ACPL-W302-560E

Part No :: ACPL-W302-560E

Manufacturer: Broadcom

VIGOR # :: 4087879

Description: OPTOISO 5KV 1CH GATE DRIVER 6SO

Catalog: Isolators - Gate Drivers

DataSheet: ACPL-W302-560E PDF

Country of origin: -

Date code: -

ACPL-W302-560E Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
Technology:	Optical Coupling
Number of Channels:	1
Voltage - Isolation:	5000Vrms
Common Mode Transient Immunity (Min):	10kV/µs
Propagation Delay tpLH / tpHL (Max):	700ns, 700ns
Pulse Width Distortion (Max):	-
Rise / Fall Time (Typ):	50ns, 50ns
Current - Output High, Low:	200mA, 200mA
Current - Peak Output:	400mA
Voltage - Forward (Vf) (Typ):	1.5V
Current - DC Forward (If) (Max):	25 mA
Voltage - Output Supply:	10V ~ 30V
Operating Temperature:	-40°C ~ 100°C
Mounting Type:	Surface Mount
Package / Case:	6-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	6-SO
Approval Agency:	CSA, IEC/EN/DIN, UR
