ACPL-W346-560E

Product image
Product thumb
Part No :

ACPL-W346-560E

Manufacturer
Broadcom
VIGOR # :

4087948

Description
OPTOISO 5KV 1CH GATE DRIVER 6SO
Catalog
Isolators - Gate Drivers
DataSheet
ACPL-W346-560E PDF
Country of origin
-
Date code
-
ads
ACPL-W346-560E Specifications
Type Description
Series:-
Package:Tape & Reel (TR)
Part Status:Active
Technology:Optical Coupling
Number of Channels:1
Voltage - Isolation:5000Vrms
Common Mode Transient Immunity (Min):50kV/µs
Propagation Delay tpLH / tpHL (Max):120ns, 120ns
Pulse Width Distortion (Max):50ns
Rise / Fall Time (Typ):8ns, 8ns
Current - Output High, Low:2A, 2A
Current - Peak Output:2.5A
Voltage - Forward (Vf) (Typ):1.55V
Current - DC Forward (If) (Max):25 mA
Voltage - Output Supply:10V ~ 20V
Operating Temperature:-40°C ~ 105°C
Mounting Type:Surface Mount
Package / Case:6-SOIC (0.268", 6.80mm Width)
Supplier Device Package:6-SO Stretched
Approval Agency:CSA, IEC/EN/DIN, UR
