Part No :

UCC21520QDWRQ1

Manufacturer
Texas Instruments
VIGOR # :

4088727

Description
4A/6A 5KVRMS DUAL ISOLATED-CHAN
Catalog
Isolators - Gate Drivers
DataSheet
UCC21520QDWRQ1 PDF
Country of origin
-
Date code
-
ads
Type Description
Series:Automotive, AEC-Q100
Package:Tape & Reel (TR)Cut Tape (CT)
Part Status:Active
Technology:Capacitive Coupling
Number of Channels:2
Voltage - Isolation:5700Vrms
Common Mode Transient Immunity (Min):100V/ns
Propagation Delay tpLH / tpHL (Max):30ns, 30ns
Pulse Width Distortion (Max):6ns
Rise / Fall Time (Typ):6ns, 7ns
Current - Output High, Low:4A, 6A
Current - Peak Output:-
Voltage - Forward (Vf) (Typ):-
Current - DC Forward (If) (Max):-
Voltage - Output Supply:3V ~ 18V
Operating Temperature:-40°C ~ 125°C
Mounting Type:Surface Mount
Package / Case:16-SOIC (0.295", 7.50mm Width)
Supplier Device Package:16-SOIC
Approval Agency:CQC, CSA, UR, VDE
