TLP701(TP,F)

Part No :: TLP701(TP,F)

Manufacturer: Toshiba Electronic Devices and Storage Corporation

VIGOR # :: 4088783

Description: OPTOISO 5KV GATE DRIVER 6SDIP GW

Catalog: Isolators - Gate Drivers

DataSheet: TLP701(TP,F) PDF

Country of origin: -

Date code: -

TLP701(TP,F) Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Not For New Designs
Technology:	Optical Coupling
Number of Channels:	1
Voltage - Isolation:	5000Vrms
Common Mode Transient Immunity (Min):	10kV/µs
Propagation Delay tpLH / tpHL (Max):	700ns, 700ns
Pulse Width Distortion (Max):	-
Rise / Fall Time (Typ):	50ns, 50ns
Current - Output High, Low:	400mA, 400mA
Current - Peak Output:	600mA
Voltage - Forward (Vf) (Typ):	1.55V
Current - DC Forward (If) (Max):	20 mA
Voltage - Output Supply:	10V ~ 30V
Operating Temperature:	-40°C ~ 100°C
Mounting Type:	Surface Mount
Package / Case:	6-SOIC (0.268", 6.80mm Width)
Supplier Device Package:	6-SDIP Gull Wing
Approval Agency:	cUL, UL
