ACPL-W314-000E

Product image
Product thumb
Part No :

ACPL-W314-000E

Manufacturer
Broadcom
VIGOR # :

4088800

Description
OPTOISO 5KV 1CH GATE DRIVER 6SO
Catalog
Isolators - Gate Drivers
DataSheet
ACPL-W314-000E PDF
Country of origin
-
Date code
-
ads
ACPL-W314-000E Specifications
Type Description
Series:-
Package:Tube
Part Status:Active
Technology:Optical Coupling
Number of Channels:1
Voltage - Isolation:5000Vrms
Common Mode Transient Immunity (Min):25kV/µs
Propagation Delay tpLH / tpHL (Max):700ns, 700ns
Pulse Width Distortion (Max):-
Rise / Fall Time (Typ):50ns, 50ns
Current - Output High, Low:400mA, 400mA
Current - Peak Output:600mA
Voltage - Forward (Vf) (Typ):1.5V
Current - DC Forward (If) (Max):25 mA
Voltage - Output Supply:10V ~ 30V
Operating Temperature:-40°C ~ 100°C
Mounting Type:Surface Mount
Package / Case:6-SOIC (0.295", 7.50mm Width)
Supplier Device Package:6-SO
Approval Agency:CSA, UR
