SI8261ABC-C-IS

Part No :: SI8261ABC-C-IS

Manufacturer: Silicon Labs

Description: DGTL ISO 3.75KV GATE DRVR 8SOIC

Catalog: Isolators - Gate Drivers

DataSheet: SI8261ABC-C-IS PDF

Availability: 290 pieces

Current price of SI8261ABC-C-IS is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SI8261ABC-C-IS Specifications

Type	Description
Series:	Automotive, AEC-Q100
Package:	Tube
Part Status:	Active
Technology:	Capacitive Coupling
Number of Channels:	1
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	35kV/µs
Propagation Delay tpLH / tpHL (Max):	60ns, 50ns
Pulse Width Distortion (Max):	28ns
Rise / Fall Time (Typ):	5.5ns, 8.5ns
Current - Output High, Low:	400mA, 600mA
Current - Peak Output:	600mA
Voltage - Forward (Vf) (Typ):	2.8V (Max)
Current - DC Forward (If) (Max):	30 mA
Voltage - Output Supply:	9.4V ~ 30V
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
Approval Agency:	CQC, CSA, UR, VDE
