ACPL-H312-060E

Part No :: ACPL-H312-060E

Manufacturer: Broadcom

VIGOR # :: 4982094

Description: OPTOISO 3.75KV 1CH GATE DRVR 8SO

Catalog: Isolators - Gate Drivers

DataSheet: ACPL-H312-060E PDF

Country of origin: -

Date code: -

ACPL-H312-060E Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Technology:	Optical Coupling
Number of Channels:	1
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	15kV/µs
Propagation Delay tpLH / tpHL (Max):	500ns, 500ns
Pulse Width Distortion (Max):	300ns
Rise / Fall Time (Typ):	50ns, 50ns
Current - Output High, Low:	2A, 2A
Current - Peak Output:	2.5A
Voltage - Forward (Vf) (Typ):	1.5V
Current - DC Forward (If) (Max):	25 mA
Voltage - Output Supply:	15V ~ 30V
Operating Temperature:	-40°C ~ 100°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.268", 6.81mm Width)
Supplier Device Package:	8-SO
Approval Agency:	CSA, IEC/EN/DIN, UR
