HCPL-3140#060

Part No :: HCPL-3140#060

Manufacturer: Broadcom

VIGOR # :: 4982246

Description: OPTOISO 3.75KV 1CH GATE DVR 8DIP

Catalog: Isolators - Gate Drivers

DataSheet: HCPL-3140#060 PDF

Country of origin: -

Date code: -

HCPL-3140#060 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Discontinued at Digi-Key
Technology:	Optical Coupling
Number of Channels:	1
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	25kV/µs
Propagation Delay tpLH / tpHL (Max):	700ns, 700ns
Pulse Width Distortion (Max):	-
Rise / Fall Time (Typ):	50ns, 50ns
Current - Output High, Low:	400mA, 400mA
Current - Peak Output:	600mA
Voltage - Forward (Vf) (Typ):	1.5V
Current - DC Forward (If) (Max):	25 mA
Voltage - Output Supply:	10V ~ 30V
Operating Temperature:	-40°C ~ 100°C
Mounting Type:	Through Hole
Package / Case:	8-DIP (0.300", 7.62mm)
Supplier Device Package:	8-DIP
Approval Agency:	CSA, IEC/EN/DIN, UR
