ACPL-071L-560E

Part No :: ACPL-071L-560E

Manufacturer: Broadcom

Description: OPTOISO 3.75KV PUSH PULL 8SO

Catalog: Optoisolators - Logic Output

DataSheet: ACPL-071L-560E PDF

Availability: 0 pieces

Unit Price: ~~$1.22642~~

Current price of ACPL-071L-560E is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ACPL-071L-560E Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
Number of Channels:	1
Inputs - Side 1/Side 2:	1/0
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	10kV/µs
Input Type:	DC
Output Type:	Push-Pull, Totem Pole
Current - Output / Channel:	10 mA
Data Rate:	15MBd
Propagation Delay tpLH / tpHL (Max):	50ns, 50ns
Rise / Fall Time (Typ):	20ns, 25ns
Voltage - Forward (Vf) (Typ):	1.5V
Current - DC Forward (If) (Max):	20mA
Voltage - Supply:	3V ~ 3.6V, 4.5V ~ 5.5V
Operating Temperature:	-40°C ~ 105°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SO
