ACPL-P484-060E

Part No :: ACPL-P484-060E

Manufacturer: Broadcom

Description: OPTOISO 3.75KV PUSH PULL 6SO

Catalog: Optoisolators - Logic Output

DataSheet: ACPL-P484-060E PDF

Availability: 0 pieces

Unit Price: ~~$1.66370~~

Current price of ACPL-P484-060E is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ACPL-P484-060E Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Number of Channels:	1
Inputs - Side 1/Side 2:	1/0
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	30kV/µs
Input Type:	DC
Output Type:	Push-Pull, Totem Pole
Current - Output / Channel:	50 mA
Data Rate:	-
Propagation Delay tpLH / tpHL (Max):	120ns, 150ns
Rise / Fall Time (Typ):	6ns, 6ns
Voltage - Forward (Vf) (Typ):	1.5V
Current - DC Forward (If) (Max):	10mA
Voltage - Supply:	4.5V ~ 30V
Operating Temperature:	-40°C ~ 105°C
Mounting Type:	Surface Mount
Package / Case:	6-SOIC (0.268", 6.80mm Width)
Supplier Device Package:	6-SO Stretched

Please confirm the specifications of the products when ordering.
