HCPL-5230

Product image
Product thumb
Part No :

HCPL-5230

Manufacturer
Broadcom
VIGOR # :

4081982

Description
OPTOISO 1.5KV 2CH PUSH PULL 8DIP
Catalog
Optoisolators - Logic Output
DataSheet
HCPL-5230 PDF
Country of origin
-
Date code
-
ads
HCPL-5230 Specifications
Type Description
Series:-
Package:Tube
Part Status:Active
Number of Channels:2
Inputs - Side 1/Side 2:2/0
Voltage - Isolation:1500VDC
Common Mode Transient Immunity (Min):1kV/µs
Input Type:DC
Output Type:Push-Pull, Totem Pole
Current - Output / Channel:15 mA
Data Rate:5MBd
Propagation Delay tpLH / tpHL (Max):350ns, 350ns
Rise / Fall Time (Typ):45ns, 10ns
Voltage - Forward (Vf) (Typ):1.3V
Current - DC Forward (If) (Max):8mA
Voltage - Supply:4.5V ~ 20V
Operating Temperature:-55°C ~ 125°C
Mounting Type:Through Hole
Package / Case:8-CDIP (0.300", 7.62mm)
Supplier Device Package:8-DIP
