ACPL-021L-500E

Part No :: ACPL-021L-500E

Manufacturer: Broadcom

VIGOR # :: 4082080

Description: OPTOISO 3.75KV PUSH PULL 8SO

Catalog: Optoisolators - Logic Output

DataSheet: ACPL-021L-500E PDF

Country of origin: Confirming

Date code: TBC

ACPL-021L-500E Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Number of Channels:	1
Inputs - Side 1/Side 2:	1/0
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	25kV/µs
Input Type:	DC
Output Type:	Push-Pull, Totem Pole
Current - Output / Channel:	10 mA
Data Rate:	5MBd
Propagation Delay tpLH / tpHL (Max):	250ns, 250ns
Rise / Fall Time (Typ):	11ns, 11ns
Voltage - Forward (Vf) (Typ):	1.5V
Current - DC Forward (If) (Max):	8mA
Voltage - Supply:	2.7V ~ 5.5V
Operating Temperature:	-40°C ~ 105°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SO
