MOC223M

Part No :: MOC223M

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: OPTOISO 2.5KV DARL W/BASE 8SOIC

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: MOC223M PDF

Availability: 7445 pieces

Unit Price: ~~$1.05000~~

Current price of MOC223M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

MOC223M Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Number of Channels:	1
Voltage - Isolation:	2500Vrms
Current Transfer Ratio (Min):	500% @ 1mA
Current Transfer Ratio (Max):	-
Turn On / Turn Off Time (Typ):	10µs, 125µs
Rise / Fall Time (Typ):	8µs, 110µs
Input Type:	DC
Output Type:	Darlington with Base
Voltage - Output (Max):	30V
Current - Output / Channel:	150mA
Voltage - Forward (Vf) (Typ):	1.08V
Current - DC Forward (If) (Max):	60 mA
Vce Saturation (Max):	1V
Operating Temperature:	-40°C ~ 100°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
