TCED4100

Part No :: TCED4100

Manufacturer: Vishay / Semiconductor - Opto Division

VIGOR # :: 4085942

Description: OPTOISOLATOR 5KV 4CH DARL 8DIP

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: TCED4100 PDF

Country of origin: -

Date code: -

TCED4100 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Number of Channels:	4
Voltage - Isolation:	5000Vrms
Current Transfer Ratio (Min):	600% @ 1mA
Current Transfer Ratio (Max):	-
Turn On / Turn Off Time (Typ):	-
Rise / Fall Time (Typ):	300µs, 250µs
Input Type:	DC
Output Type:	Darlington
Voltage - Output (Max):	35V
Current - Output / Channel:	80mA
Voltage - Forward (Vf) (Typ):	1.15V
Current - DC Forward (If) (Max):	60 mA
Vce Saturation (Max):	1V
Operating Temperature:	-40°C ~ 100°C
Mounting Type:	Through Hole
Package / Case:	16-DIP (0.300", 7.62mm)
Supplier Device Package:	16-DIP
