PT5110C

Part No :: PT5110C

Manufacturer: VIGOR

VIGOR # :: 4099459

Description: SWITCHING REGLTR, VOLTAGE-MODE

Catalog: DC DC Converters

DataSheet: PT5110C PDF

Country of origin: -

Date code: -

PT5110C Specifications

Type	Description
Series:	PT5100
Package:	Tray
Part Status:	Obsolete
Type:	Linear Regulator Replacement
Number of Outputs:	1
Voltage - Input (Min):	13V
Voltage - Input (Max):	38V
Voltage - Output 1:	9V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1A
Power (Watts):	9 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	OCP, OTP
Operating Temperature:	-40°C ~ 85°C
Efficiency:	91%
Mounting Type:	Surface Mount
Package / Case:	3-SMD Module
Size / Dimension:	1.00" L x 1.02" W x 0.38" H (25.4mm x 25.9mm x 9.7mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
PT5112C Match 84%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT5110C vs PT5112C
PT5105C Match 52%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT5110C vs PT5105C
PT5112CT Match 84%	Texas Instruments DC DC CONVERTER 8V 8W	PT5110C vs PT5112CT
PT5110CT Match 100%	Texas Instruments DC DC CONVERTER 9V 9W	PT5110C vs PT5110CT
PT5112L Match 84%	Texas Instruments DC DC CONVERTER 8V 8W	PT5110C vs PT5112L
PT5110L Match 100%	Texas Instruments DC DC CONVERTER 9V 9W	PT5110C vs PT5110L

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 585

Shipped from

HK warehouse

Expected Shipping Date

Aug 25 - Aug 29 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$7.8900~~	~~$7.89~~

Current price of PT5110C is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
