HEA2-12S24

Part No :: HEA2-12S24

Manufacturer: Daburn

VIGOR # :: 4102889

Description: DC DC CONVERTER 24V 2W

Catalog: DC DC Converters

DataSheet: HEA2-12S24 PDF

Country of origin: -

Date code: -

HEA2-12S24 Specifications

Type	Description
Series:	HEA2 (2W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	9V
Voltage - Input (Max):	18V
Voltage - Output 1:	24V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	83mA
Power (Watts):	2 W
Voltage - Isolation:	1.6 kV
Applications:	ITE (Commercial)
Features:	Remote On/Off
Operating Temperature:	-40°C ~ 105°C (With Derating)
Efficiency:	85%
Mounting Type:	Through Hole
Package / Case:	8-SIP Module, 7 Leads
Size / Dimension:	0.86" L x 0.36" W x 0.44" H (21.8mm x 9.1mm x 11.2mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	CE
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
EDL02-24S24W Match 100%	P-Duke Technology, Inc. DC DC CONVERTER 24V 2W	HEA2-12S24 vs EDL02-24S24W
EDL02-12S24 Match 100%	P-Duke Technology, Inc. DC DC CONVERTER 24V 2W	HEA2-12S24 vs EDL02-12S24
EDL03-12S24W Match 71%	P-Duke Technology, Inc. ISOLATED /3W /VOUT:24	HEA2-12S24 vs EDL03-12S24W
EDL03-24S24W Match 71%	P-Duke Technology, Inc. DC DC CONVERTER 24V 3W	HEA2-12S24 vs EDL03-24S24W
PQMC3-D12-S24-S Match 70%	CUI Inc. DC DC CONVERTER 24V 3W	HEA2-12S24 vs PQMC3-D12-S24-S

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 568

Shipped from

HK warehouse

Expected Shipping Date

Jul 22 - Jul 26 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$18.5500~~	~~$18.55~~

Current price of HEA2-12S24 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
