VX7805-1000

Part No :: VX7805-1000

Manufacturer: CUI Inc.

VIGOR # :: 4103854

Description: DC DC CONVERTER 5V 5W

Catalog: DC DC Converters

DataSheet: VX7805-1000 PDF

Country of origin: -

Date code: -

VX7805-1000 Specifications

Type	Description
Series:	VX78-1000
Package:	Tube
Part Status:	Active
Type:	Linear Regulator Replacement
Number of Outputs:	1
Voltage - Input (Min):	8V
Voltage - Input (Max):	36V
Voltage - Output 1:	5V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1A
Power (Watts):	5 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 85°C (With Derating)
Efficiency:	93%
Mounting Type:	Through Hole
Package / Case:	3-SIP Module
Size / Dimension:	0.45" L x 0.35" W x 0.69" H (11.5mm x 9.0mm x 17.5mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	CB Scheme, EN, IEC, UL
Standard Number:	55024; 55032 Class A; 60950-1

Alternative Products

Part Number	Manufacturer & Description	Compare
TSR 1-2450 Match 100%	TRACO Power DC DC CONVERTER 5V 5W	VX7805-1000 vs TSR 1-2450
R-78C5.0-1.0 Match 100%	RECOM Power DC DC CONVERTER 5V 5W	VX7805-1000 vs R-78C5.0-1.0
VR10S05 Match 100%	XP Power DC DC CONVERTER 5V	VX7805-1000 vs VR10S05
TSRN 1-2450 Match 100%	TRACO Power DC DC CONVERTER 5V 5W	VX7805-1000 vs TSRN 1-2450
TSRN 1-2450A Match 100%	TRACO Power DC DC CONVERTER 5V 5W	VX7805-1000 vs TSRN 1-2450A
173010542 Match 100%	Würth Elektronik Midcom DC DC CONVERTER 5V	VX7805-1000 vs 173010542

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 2351

Shipped from

HK warehouse

Expected Shipping Date

Jul 22 - Jul 26 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$3.3600~~	~~$3.36~~
5	~~$3.3092~~	~~$16.55~~
10	~~$3.2615~~	~~$32.62~~
44	~~$3.1655~~	~~$139.28~~
88	~~$3.0697~~	~~$270.13~~
132	~~$2.9737~~	~~$392.53~~
264	~~$2.8778~~	~~$759.74~~
528	~~$2.6860~~	~~$1 418.19~~

Current price of VX7805-1000 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
