AMSR-7809Z

Part No :: AMSR-7809Z

Manufacturer: DComponents

VIGOR # :: 4116816

Description: DC DC CONVERTER 9V 4.5W

Catalog: DC DC Converters

DataSheet: AMSR-7809Z PDF

Country of origin: -

Date code: -

AMSR-7809Z Specifications

Type	Description
Series:	AMSR-78Z (7.5W)
Package:	Tube
Part Status:	Active
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	11V
Voltage - Input (Max):	34V
Voltage - Output 1:	9V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	500mA
Power (Watts):	4.5 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 85°C
Efficiency:	96%
Mounting Type:	Through Hole
Package / Case:	3-SIP Module
Size / Dimension:	0.46" L x 0.29" W x 0.40" H (11.7mm x 7.5mm x 10.2mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	CE
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
AMSR-787.2Z Match 69%	DComponents DC DC CONVERTER 7.2V 3.6W	AMSR-7809Z vs AMSR-787.2Z
LCN78_09-0.5 Match 100%	TE Connectivity AMP Connectors DC-DC POL	AMSR-7809Z vs LCN78_09-0.5
AMSRW-786.5Z Match 55%	DComponents DC DC CONVERTER 6.5V 3.3W	AMSR-7809Z vs AMSRW-786.5Z
AMSR-786.5Z Match 55%	DComponents DC DC CONVERTER 6.5V 3.3W	AMSR-7809Z vs AMSR-786.5Z
LCW78_06-0.5 Match 55%	TE Connectivity AMP Connectors DC-DC POL	AMSR-7809Z vs LCW78_06-0.5
AMSRW-786.5-NZ Match 55%	DComponents DC DC CONVERTER 6.5V 3.25W	AMSR-7809Z vs AMSRW-786.5-NZ
