CHVM3-12-0300NW

Part No :: CHVM3-12-0300NW

Manufacturer: TDK-Lambda, Inc.

VIGOR # :: 4129218

Description: DC DC CONVERTER -300V 3W

Catalog: DC DC Converters

DataSheet: CHVM3-12-0300NW PDF

Country of origin: -

Date code: -

CHVM3-12-0300NW Specifications

Type	Description
Series:	CHVM (3W)
Package:	Box
Part Status:	Active
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	10.8V
Voltage - Input (Max):	13.2V
Voltage - Output 1:	-300V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	10mA
Power (Watts):	3 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	Adjustable Output, Remote On/Off, Remote Sense
Operating Temperature:	-10°C ~ 60°C (With Derating)
Efficiency:	-
Mounting Type:	Through Hole
Package / Case:	6-SIP Module
Size / Dimension:	3.15" L x 0.47" W x 0.78" H (80.0mm x 12.0mm x 19.8mm)
Supplier Device Package:	-
Control Features:	Enable, Active Low
Approval Agency:	CE, CSA, UL
Standard Number:	62368-1

Alternative Products

Part Number	Manufacturer & Description	Compare
CHVM2R5-12-0350NW Match 58%	TDK-Lambda, Inc. DC DC CONVERTER -350V 2.5W	CHVM3-12-0300NW vs CHVM2R5-12-0350NW
CHVM2R7-12-0180NW Match 60%	TDK-Lambda, Inc. DC DC CONVERTER -180V 2.7W	CHVM3-12-0300NW vs CHVM2R7-12-0180NW
CHVM2R5-12-0350PW Match 58%	TDK-Lambda, Inc. DC DC CONVERTER 350V 2.5W	CHVM3-12-0300NW vs CHVM2R5-12-0350PW
CHVM3-12-0300PW Match 100%	TDK-Lambda, Inc. DC DC CONVERTER 300V 3W	CHVM3-12-0300NW vs CHVM3-12-0300PW
CHVM2R7-12-0180PW Match 60%	TDK-Lambda, Inc. DC DC CONVERTER 180V 2.7W	CHVM3-12-0300NW vs CHVM2R7-12-0180PW

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 633

Shipped from

HK warehouse

Expected Shipping Date

Jul 21 - Jul 25 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$222.2400~~	~~$222.24~~

Current price of CHVM3-12-0300NW is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
