VI-J23-MX – Vicor 75W Isolated Module

Part No :: VI-J23-MX

Manufacturer: Vicor

VIGOR # :: 4147437

Description: DC DC CONVERTER 24V 75W

Catalog: DC DC Converters

DataSheet: VI-J23-MX PDF

Country of origin: -

Date code: -

Product Description

The VI-J23-MX from Vicor is a 75W isolated module in the VI-J00 family.

The module accepts a 21V to 56V input range and provides a stable, well-regulated 24V output, delivering up to 3.13A of output current.

Review the complete VI-J23-MX specifications below, or request a quote for current stock and lead-time pricing.

VI-J23-MX Specifications

Type	Description
Series:	VI-J00™ (75W)
Package:	Bulk
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	21V
Voltage - Input (Max):	56V
Voltage - Output 1:	24V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	3.13A
Power (Watts):	75 W
Voltage - Isolation:	3 kV
Applications:	ITE (Commercial)
Features:	OCP, SCP
Operating Temperature:	-55°C ~ 100°C
Efficiency:	90%
Mounting Type:	Through Hole
Package / Case:	Half Brick
Size / Dimension:	2.28" L x 2.40" W x 0.50" H (57.9mm x 70.0mm x 12.7mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
VI-J23-MX-F4 Match 100%	Vicor DC DC CONVERTER 24V 75W	VI-J23-MX vs VI-J23-MX-F4
VI-J23-MX-F2 Match 100%	Vicor DC DC CONVERTER 24V 75W	VI-J23-MX vs VI-J23-MX-F2
VI-J23-MX-F3 Match 100%	Vicor DC DC CONVERTER 24V 75W	VI-J23-MX vs VI-J23-MX-F3
VI-J23-MX-B1 Match 100%	Vicor DC DC CONVERTER 24V 75W	VI-J23-MX vs VI-J23-MX-B1
VI-J23-MX-S Match 100%	Vicor DC DC CONVERTER 24V 75W	VI-J23-MX vs VI-J23-MX-S
VI-J23-MX-F1 Match 100%	Vicor DC DC CONVERTER 24V 75W	VI-J23-MX vs VI-J23-MX-F1
