AM1DR-0515S-NZ

Part No :: AM1DR-0515S-NZ

Manufacturer: DComponents

VIGOR # :: 4148650

Description: DC DC CONVERTER 15V 1W

Catalog: DC DC Converters

DataSheet: AM1DR-0515S-NZ PDF

Country of origin: -

Date code: -

AM1DR-0515S-NZ Specifications

Type	Description
Series:	AM1DR-NZ (1W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	5.5V
Voltage - Output 1:	15V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	67mA
Power (Watts):	1 W
Voltage - Isolation:	1 kV
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 71°C (With Derating)
Efficiency:	72%
Mounting Type:	Through Hole
Package / Case:	7-SIP Module, 4 Leads
Size / Dimension:	0.77" L x 0.24" W x 0.37" H (19.6mm x 6.0mm x 9.5mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	cULus, cURus
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
AM1DR-0515SH30JZ Match 86%	DComponents DC DC CONVERTER 15V 1W	AM1DR-0515S-NZ vs AM1DR-0515SH30JZ
AM1DE-0515SH30Z Match 86%	DComponents DC DC CONVERTER 15V 1W	AM1DR-0515S-NZ vs AM1DE-0515SH30Z
PF01S0515A Match 86%	Delta Electronics / Power DC DC CONVERTER 15V 1W	AM1DR-0515S-NZ vs PF01S0515A
TMV 0515S Match 86%	TRACO Power DC DC CONVERTER 15V 1W	AM1DR-0515S-NZ vs TMV 0515S
DCH010515SN7 Match 86%	Texas Instruments DC DC CONVERTER 15V 1W	AM1DR-0515S-NZ vs DCH010515SN7
B0515LS-1WR3 Match 95%	Mornsun DC DC CONVERTER 15V 1W	AM1DR-0515S-NZ vs B0515LS-1WR3

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 984

Shipped from

HK warehouse

Expected Shipping Date

Aug 31 - Sep 04 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$4.3300~~	~~$4.33~~

Current price of AM1DR-0515S-NZ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
