CHVM2-12-1500NW

Part No :: CHVM2-12-1500NW

Manufacturer: TDK-Lambda, Inc.

VIGOR # :: 4152220

Description: DC DC CONVERTER -1500V 2W

Catalog: DC DC Converters

DataSheet: CHVM2-12-1500NW PDF

Country of origin: -

Date code: -

CHVM2-12-1500NW Specifications

Type	Description
Series:	CHVM (3W)
Package:	Box
Part Status:	Active
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	10.8V
Voltage - Input (Max):	16.5V
Voltage - Output 1:	-1500V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1.3mA
Power (Watts):	1.95 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	Adjustable Output, Remote On/Off, Remote Sense
Operating Temperature:	-10°C ~ 60°C (With Derating)
Efficiency:	-
Mounting Type:	Through Hole
Package / Case:	7-SIP Module
Size / Dimension:	4.33" L x 0.47" W x 0.78" H (110.0mm x 12.0mm x 19.8mm)
Supplier Device Package:	-
Control Features:	Enable, Active Low
Approval Agency:	CE, CSA, UL
Standard Number:	62368-1

Alternative Products

Part Number	Manufacturer & Description	Compare
CHVM2-12-1000NW Match 63%	TDK-Lambda, Inc. DC DC CONVERTER -1000V 2W	CHVM2-12-1500NW vs CHVM2-12-1000NW
CHVM2-12-1000PW Match 63%	TDK-Lambda, Inc. DC DC CONVERTER 1000V 2W	CHVM2-12-1500NW vs CHVM2-12-1000PW
CHVM2-12-2000PW Match 77%	TDK-Lambda, Inc. DC DC CONVERTER 2000V 2W	CHVM2-12-1500NW vs CHVM2-12-2000PW
CHVM2-12-2000NW Match 77%	TDK-Lambda, Inc. DC DC CONVERTER -2000V 2W	CHVM2-12-1500NW vs CHVM2-12-2000NW
CHVM2-12-1500PW Match 82%	TDK-Lambda, Inc. DC DC CONVERTER 1500V 2W	CHVM2-12-1500NW vs CHVM2-12-1500PW

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 506

Shipped from

HK warehouse

Expected Shipping Date

Aug 29 - Sep 02 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$333.8700~~	~~$333.87~~

Current price of CHVM2-12-1500NW is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
