AM4T-0505SH35Z

Part No :: AM4T-0505SH35Z

Manufacturer: DComponents

VIGOR # :: 4165278

Description: DC DC CONVERTER 5V 4W

Catalog: DC DC Converters

DataSheet: AM4T-0505SH35Z PDF

Country of origin: -

Date code: -

AM4T-0505SH35Z Specifications

Type	Description
Series:	AM4T-Z (4W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	9V
Voltage - Output 1:	5V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	800mA
Power (Watts):	4 W
Voltage - Isolation:	3.5 kV
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 85°C
Efficiency:	78%
Mounting Type:	Through Hole
Package / Case:	24-DIP Module, 7 Leads
Size / Dimension:	1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	CE
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
JCD0405S05 Match 90%	XP Power DC DC CONVERTER 5V 4W	AM4T-0505SH35Z vs JCD0405S05
AM4T-0505SZ Match 100%	DComponents DC DC CONVERTER 5V 4W	AM4T-0505SH35Z vs AM4T-0505SZ
REC3.5-0505SRW/R8/A/CTRL Match 80%	RECOM Power DC DC CONVERTER 5V 3.5W	AM4T-0505SH35Z vs REC3.5-0505SRW/R8/A/CTRL
JCA0405S05 Match 89%	XP Power DC DC CONVERTER 5V 4W	AM4T-0505SH35Z vs JCA0405S05
REM3.5E-0505S/R8/A/CTRL Match 80%	RECOM Power DC DC CONVERTER 5V 3.5W	AM4T-0505SH35Z vs REM3.5E-0505S/R8/A/CTRL
REM3.5E-0505S/R8/A Match 80%	RECOM Power DC DC CONVERTER 5V 3.5W	AM4T-0505SH35Z vs REM3.5E-0505S/R8/A

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 914

Shipped from

HK warehouse

Expected Shipping Date

Sep 10 - Sep 14 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$16.0200~~	~~$16.02~~

Current price of AM4T-0505SH35Z is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
