PTN78000AAZ

Part No :: PTN78000AAZ

Manufacturer: VIGOR

VIGOR # :: 4166319

Description: PTN78000A 1.5 A, WIDE INPUT, NON

Catalog: DC DC Converters

DataSheet: PTN78000AAZ PDF

Country of origin: -

Date code: -

PTN78000AAZ Specifications

Type	Description
Series:	PTN78000A
Package:	Bulk
Part Status:	Active
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	7V
Voltage - Input (Max):	28.7V
Voltage - Output 1:	-15 ~ -3V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1.5A
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	OTP, UVLO
Operating Temperature:	-40°C ~ 85°C
Efficiency:	84%
Mounting Type:	Surface Mount
Package / Case:	5-SMD Module
Size / Dimension:	0.75" L x 0.50" W x 0.36" H (19.1mm x 12.7mm x 9.1mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-
