CHVM1R5-12-1500P

Part No :: CHVM1R5-12-1500P

Manufacturer: TDK-Lambda, Inc.

VIGOR # :: 4168692

Description: DC DC CONVERTER 1500V 1.5W

Catalog: DC DC Converters

DataSheet: CHVM1R5-12-1500P PDF

Country of origin: -

Date code: -

CHVM1R5-12-1500P Specifications

Type	Description
Series:	CHVM (3W)
Package:	Box
Part Status:	Active
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	11V
Voltage - Input (Max):	13V
Voltage - Output 1:	1500V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1mA
Power (Watts):	1.5 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	Adjustable Output, Remote On/Off, Remote Sense
Operating Temperature:	-10°C ~ 50°C
Efficiency:	-
Mounting Type:	Through Hole
Package / Case:	7-SIP Module
Size / Dimension:	1.73" L x 0.63" W x 1.18" H (44.0mm x 16.0mm x 30.0mm)
Supplier Device Package:	-
Control Features:	Enable, Active High
Approval Agency:	CE, CSA, UL
Standard Number:	62368-1

Alternative Products

Part Number	Manufacturer & Description	Compare
CHVM1R5-12-1000N Match 67%	TDK-Lambda, Inc. DC DC CONVERTER -1000V 1.5W	CHVM1R5-12-1500P vs CHVM1R5-12-1000N
CHVM2-12-2000PW Match 60%	TDK-Lambda, Inc. DC DC CONVERTER 2000V 2W	CHVM1R5-12-1500P vs CHVM2-12-2000PW
CHVM1R5-12-1500N Match 100%	TDK-Lambda, Inc. DC DC CONVERTER -1500V 1.5W	CHVM1R5-12-1500P vs CHVM1R5-12-1500N
CHVM2-12-1500NW Match 62%	TDK-Lambda, Inc. DC DC CONVERTER -1500V 2W	CHVM1R5-12-1500P vs CHVM2-12-1500NW
CHVM2-12-2000NW Match 82%	TDK-Lambda, Inc. DC DC CONVERTER -2000V 2W	CHVM1R5-12-1500P vs CHVM2-12-2000NW
CHVM2-12-1500PW Match 68%	TDK-Lambda, Inc. DC DC CONVERTER 1500V 2W	CHVM1R5-12-1500P vs CHVM2-12-1500PW

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 425

Shipped from

HK warehouse

Expected Shipping Date

Aug 23 - Aug 27 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$235.6600~~	~~$235.66~~

Current price of CHVM1R5-12-1500P is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
