VI-J24-EX-F2 – Vicor 75W Isolated Module

Part No :: VI-J24-EX-F2

Manufacturer: Vicor

VIGOR # :: 4989451

Description: DC DC CONVERTER 48V 75W

Catalog: DC DC Converters

DataSheet: VI-J24-EX-F2 PDF

Country of origin: -

Date code: -

Product Description

Vicor's VI-J24-EX-F2 is a 75W isolated module in the VI-J00 family.

The module accepts a 21V to 56V input range and provides a stable, well-regulated 48V output, delivering up to 1.56A of output current.

Full specifications are listed below — submit an RFQ for today's best price.

VI-J24-EX-F2 Specifications

Type	Description
Series:	VI-J00™ (75W)
Package:	Bulk
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	21V
Voltage - Input (Max):	56V
Voltage - Output 1:	48V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1.56A
Power (Watts):	75 W
Voltage - Isolation:	3 kV
Applications:	ITE (Commercial)
Features:	OCP, SCP
Operating Temperature:	-10°C ~ 100°C
Efficiency:	88%
Mounting Type:	Through Hole
Package / Case:	Half Brick
Size / Dimension:	2.28" L x 1.86" W x 1.04" H (57.9mm x 47.2mm x 26.4mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
VI-J24-MX-F2 Match 100%	Vicor DC DC CONVERTER 48V 75W	VI-J24-EX-F2 vs VI-J24-MX-F2
VI-J24-CX-F1 Match 100%	Vicor DC DC CONVERTER 48V 75W	VI-J24-EX-F2 vs VI-J24-CX-F1
VI-J24-EX-F3 Match 100%	Vicor DC DC CONVERTER 48V 75W	VI-J24-EX-F2 vs VI-J24-EX-F3
VI-J24-MX-F3 Match 100%	Vicor DC DC CONVERTER 48V 75W	VI-J24-EX-F2 vs VI-J24-MX-F3
VI-J24-IX-S Match 100%	Vicor DC DC CONVERTER 48V 75W	VI-J24-EX-F2 vs VI-J24-IX-S
VI-J24-MX-B1 Match 100%	Vicor DC DC CONVERTER 48V 75W	VI-J24-EX-F2 vs VI-J24-MX-B1
