UCQ-5/20-D48NHL2-Y

Part No :: UCQ-5/20-D48NHL2-Y

Manufacturer: Murata Power Solutions

VIGOR # :: 4997770

Description: DC DC CONVERTER 5V 100W

Catalog: DC DC Converters

DataSheet: UCQ-5/20-D48NHL2-Y PDF

Country of origin: Confirming

Date code: TBC

UCQ-5/20-D48NHL2-Y Specifications

Type	Description
Series:	UCQ
Package:	Tube
Part Status:	Obsolete
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	36V
Voltage - Input (Max):	75V
Voltage - Output 1:	5V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	20A
Power (Watts):	100 W
Voltage - Isolation:	2.25 kV
Applications:	ITE (Commercial)
Features:	Remote On/Off, OTP, OVP, SCP
Operating Temperature:	-40°C ~ 85°C
Efficiency:	92%
Mounting Type:	Through Hole
Package / Case:	8-DIP Module, 1/4 Brick
Size / Dimension:	2.30" L x 1.45" W x 0.40" H (58.4mm x 36.8mm x 10.0mm)
Supplier Device Package:	-
Control Features:	Enable, Active Low
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
UVQ-5/20-D48N-C Match 100%	Murata Power Solutions DC DC CONVERTER 5V 100W	UCQ-5/20-D48NHL2-Y vs UVQ-5/20-D48N-C
UQQ-5/20-Q48P-C Match 100%	Murata Power Solutions DC DC CONVERTER 5V 100W	UCQ-5/20-D48NHL2-Y vs UQQ-5/20-Q48P-C
PAQ100S485/BV Match 95%	TDK-Lambda, Inc. DC DC CONVERTER 5V 100W	UCQ-5/20-D48NHL2-Y vs PAQ100S485/BV
PAQ100S485/BPV Match 95%	TDK-Lambda, Inc. DC DC CONVERTER 5V 100W	UCQ-5/20-D48NHL2-Y vs PAQ100S485/BPV
UVQ-5/20-D48PB-C Match 100%	Murata Power Solutions DC DC CONVERTER 5V 100W	UCQ-5/20-D48NHL2-Y vs UVQ-5/20-D48PB-C
UVQ-5/20-D48NB-C Match 100%	Murata Power Solutions DC DC CONVERTER 5V 100W	UCQ-5/20-D48NHL2-Y vs UVQ-5/20-D48NB-C
