PT6525D

Part No :: PT6525D

Manufacturer: Texas Instruments

VIGOR # :: 5002091

Description: DC DC CONVERTER 2.1V

Catalog: DC DC Converters

DataSheet: PT6525D PDF

Country of origin: -

Date code: -

PT6525D Specifications

Type	Description
Series:	PT6520
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	3.1V
Voltage - Input (Max):	5.5V
Voltage - Output 1:	2.1V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	8A
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 85°C
Efficiency:	82%
Mounting Type:	Through Hole, Right Angle
Package / Case:	14-SIP Module
Size / Dimension:	-
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
PT6526D Match 79%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT6525D vs PT6526D
PT6506A Match 79%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT6525D vs PT6506A
PT6526G Match 79%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT6525D vs PT6526G
PT6523G Match 76%	Texas Instruments DC DC CONVERTER 2.5V	PT6525D vs PT6523G
PT6525G Match 100%	Texas Instruments DC DC CONVERTER 2.1V	PT6525D vs PT6525G
PT6506G Match 79%	Texas Instruments DC DC CONVERTER 1.8V	PT6525D vs PT6506G
