PT6523P

Part No :: PT6523P

Manufacturer: Texas Instruments

VIGOR # :: 5016611

Description: DC DC CONVERTER 2.5V

Catalog: DC DC Converters

DataSheet: PT6523P PDF

Country of origin: -

Date code: -

PT6523P Specifications

Type	Description
Series:	PT6520
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	3.1V
Voltage - Input (Max):	5.5V
Voltage - Output 1:	2.5V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	8A
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 85°C
Efficiency:	85%
Mounting Type:	Through Hole
Package / Case:	14-SIP Module
Size / Dimension:	-
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
PT6523R Match 100%	Texas Instruments DC DC CONVERTER 2.5V	PT6523P vs PT6523R
PT6525P Match 76%	Texas Instruments DC DC CONVERTER 2.1V	PT6523P vs PT6525P
PT6526R Match 55%	Texas Instruments DC DC CONVERTER 1.8V	PT6523P vs PT6526R
PT6525R Match 76%	Texas Instruments DC DC CONVERTER 2.1V	PT6523P vs PT6525R
PT6506R Match 55%	Texas Instruments DC DC CONVERTER 1.8V	PT6523P vs PT6506R
PT6526P Match 55%	Texas Instruments DC DC CONVERTER 1.8V	PT6523P vs PT6526P
