MPDTH05020WAS

Part No :: MPDTH05020WAS

Manufacturer: Murata Power Solutions

VIGOR # :: 5018531

Description: DC DC CONVERTER 0.8-3.6V 79W

Catalog: DC DC Converters

DataSheet: MPDTH05020WAS PDF

Country of origin: -

Date code: -

MPDTH05020WAS Specifications

Type	Description
Series:	MPD
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	5.5V
Voltage - Output 1:	0.8 ~ 3.6V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	22A
Power (Watts):	79 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	Remote On/Off, OCP, UVLO
Operating Temperature:	-40°C ~ 85°C
Efficiency:	95%
Mounting Type:	Surface Mount
Package / Case:	10-SMD Module
Size / Dimension:	1.50" L x 0.87" W x 0.38" H (38.1mm x 22.1mm x 9.6mm)
Supplier Device Package:	-
Control Features:	Enable, Active High
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
PTH05020WAZ Match 100%	VIGOR PTH05020W 22 A, 5-V INPUT WIDE-O	MPDTH05020WAS vs PTH05020WAZ
PTH05020WAS Match 100%	Texas Instruments DC DC CONVERTER 0.8-3.6V 79W	MPDTH05020WAS vs PTH05020WAS
BR206 Match 87%	Sanken Electric Co., Ltd. DC DC CONVERTER 0.75-3.63V 73W	MPDTH05020WAS vs BR206
PTH05020WAST Match 100%	Texas Instruments DC DC CONVERTER 0.8-3.6V 79W	MPDTH05020WAS vs PTH05020WAST
PTH05020WAZT Match 100%	Texas Instruments DC DC CONVERTER 0.8-3.6V 79W	MPDTH05020WAS vs PTH05020WAZT
PMH5718TSR Match 95%	Flex Power Modules DC DC CONVERTER 0.8-3.3V 73W	MPDTH05020WAS vs PMH5718TSR
