PT6308N

Part No :: PT6308N

Manufacturer: Texas Instruments

VIGOR # :: 5033090

Description: DC DC CONVERTER 1.2V

Catalog: DC DC Converters

DataSheet: PT6308N PDF

Country of origin: -

Date code: -

PT6308N Specifications

Type	Description
Series:	PT6305
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	6V
Voltage - Output 1:	1.2V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	3A
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	0°C ~ 70°C
Efficiency:	57%
Mounting Type:	Through Hole
Package / Case:	12-SIP Module
Size / Dimension:	2.06" L x 0.38" W x 0.67" H (52.3mm x 9.7mm x 17.0mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
PT6308S Match 100%	VIGOR DC-DC POWER SUPPLY MODULE	PT6308N vs PT6308S
R-551.2PA Match 67%	RECOM Power DC DC CONVERTER 1.2V 6W	PT6308N vs R-551.2PA
R-541.2PA Match 82%	RECOM Power DC DC CONVERTER 1.2V 4.8W	PT6308N vs R-541.2PA
R-531.2PA Match 100%	RECOM Power DC DC CONVERTER 1.2V 3.6W	PT6308N vs R-531.2PA
R-521.2PA Match 74%	RECOM Power DC DC CONVERTER 1.2V 2.4W	PT6308N vs R-521.2PA
